3 Port HDMI 2.0 18GBPS AV Switch

Cost effective HDMI Switcher to suit new HDMI devices

SKU: AA6300


$34.95
RRP $79.95
Sold Out

Buy In Bulk & Save!
Buy 4 to 10: Pay $33.20 ea
Buy 11 to 20: Pay $29.88 ea
Buy 21 to 100: Pay $26.89 ea




Calculate Shipping

3 Port HDMI 2.0 18GBPS AV Switcher

Cost effective HDMI Switcher to suit new HDMI devices

This is a high performance 3 HDMI input selector to 1 HDMI output switch box. This HDMI Switch supports HDCP repeater functions and fast switching between any of the HDMI ports. The system supports all 3D TV formats in addition to all HDTV formats up to 4Kx2K. Furthermore, the remote control gives complete control over the selection of sources and makes the device incredibly user friendly.

Features:

• HDCP 2.2/1.x and DVI 1.0 compliant

• Support 18Gbps video bandwidth

• HDR, HDR10, Dolby Vision and HLG are supported

• Support video resolution up to 4K2K@50/60Hz YCbCr 4:4:4

• Support 3D video format • Low power consumption

• Support IR remote control and panel button control

• Compact design for easy and flexible installation

Package:

  • HDMI 2.0 Switcher

  • 5V USB to DC Power Supply cable

  • Remote control

  • IR Receive Extend cable

  • Operation Manual

Technical

HDMI Compliance

HDMI 2.0b

HDCP Compliance

HDCP 2.2 and HDCP 1.4

Video Bandwidth

1 Gbps

Video Resolutions

up to 4K2K@50/60Hz(YUV4:4:4),4K2K@30Hz,1080P@120Hz, and 1080P 3D@60Hz

Color Space

RGB   YCbCr 4:4:4, YCbCr 4:2:2

Color Depth

1 -bit,   12-bit

HDMI Audio Formats
(Pass-through)

LPCM   2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD   Master Audio, Dolby Atmos, DTS:X

ESD Protection

Human   body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)

Connections

Inputs

3x HDMI Type A [19-pin female]

Outputs

1x HDMI Type A [19-pin female]

Mechanical

Housing nbsp;

Plastic Enclosure

Color

Gray

Dimensions

1 0mm [W] x 79mm [D] x 16mm [H]

Weight

2 0g

Power Supply

Input   AC100 - 240V 50/60Hz

Output DC 5V/1A (US/EU standards, CE/FCC/UL certified)

Power Consumption

1W   (Max)

Operation Temperature


32 - 104°F / 0 - 40°C

Storage temperature

- - 140°F / -20 - 60°C

Relative Humidity

20 - 90% RH (no condensation)

Do I need a HDMI Switcher of a HDMI Splitter?

CLICK HERE TO SEE OTHER 4K HDMI SWITCHERS IN OUR RANGE



3 Month Warranty

SKU AA6300
Barcode # 9351634025640
Brand Playvision
Shipping Weight 0.2100kg
Shipping Width 0.120m
Shipping Height 0.080m
Shipping Length 0.130m
Shipping Cubic 0.001248000m3
Unit Of Measure ea
Assembled Length 0.150m
Assembled Height 0.020m
Assembled Width 0.100m
