2 Way HDMI 2.0 18GBPS UHD Splitter

2 Way HDMI Splitter with HDCP and EDID Settings

SKU: AA6094

RRP $159.95
Sold Out

Buy In Bulk & Save!
Buy 4 to 10: Pay $56.95 ea
Buy 11 to 20: Pay $54.10 ea
Buy 21 to 100: Pay $51.40 ea

Calculate Shipping

2 Way HDMI 2.0 18GBPS UHD Splitter

2 Way HDMI Splitter with HDCP and EDID Settings

This 2 output HDMI high bandwidth Splitter is an advanced solution for splitting a HDMI signal to two HDMI displays. It provides high performance audio and video output through HDMI cables up to 4K2K@60Hz (YUV4:4:4) and is capable of receiving and transmitting up to 18Gbps of bandwidth with no data loss. Perfect for new 4K video sources such as Playstation 4 Pro or Xbox S One and other devices that require 4K2K@60Hz with 24bit RGB/YCBCR 4:4:4 / YCBCR 4:2:2 specifications.

• HDMI 2.0b, HDCP 2.2 compliant
• Supports High Definition resolutions up to 4K2K @ 60Hz with 24bit RGB / YCBCR 4:4:4 / YCBCR 4:2:2
• Supports 3D frame sequential video format up to 4K2K@30Hz
• Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
• HDMI input supports 'Standard' mode and 'TV' mode EDID settings
• Compact design for an easy and flexible installation


HDMI Compliance : HDMI 2.0b
HDCP Compliance : HDCP 2.2
Video Bandwidth : 18 Gbps
Video Resolutions : up to 4K2K @ 60Hz(4:4:4), 4K2K @ 30Hz, 1080P @ 120Hz, and 1080P 3D @ 60Hz
Supports HDR: Yes
Color Space : RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth : 10-bit, 12-bit
Audio Formats : PCM 2CH, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1, Dolby   Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
ESD Protection  : Human body model — ±8kV (air-gap discharge) & ±4kV (contact   discharge)

Inputs : 1x HDMI Type A [19-pin female]
Outputs : 2x HDMI Type A [19-pin female]

Housing : Metal Enclosure
Dimensions : 56mm [W] x 96mm [D] x 17mm [H]
Net Weight : 100g
Power Supply : DC 5V/1A
Power Consumption (Max) : 3W
Operation Temperature : 32 - 104°F / 0 - 40°C
Storage temperature : -4 - 140°F / -20 - 60°C
Relative Humidity : 20 - 90% RH (no condensation)


What is a HDMI Splitter?

Do I need a HDMI Switcher of a HDMI Splitter?



12 Month Warranty

SKU AA6094
Barcode # 9351634008285
Brand Playvision
Shipping Weight 0.3200kg
Shipping Width 0.130m
Shipping Height 0.070m
Shipping Length 0.170m
Shipping Cubic 0.001547000m3
Unit Of Measure ea
Assembled Length 0.100m
Assembled Height 0.010m
Assembled Width 0.150m

2 Way HDMI 2.0 18GBPS UHD Splitter

By: on 22 February 2018
Excellent product, would thoroughly recommend for anyone wanting to buy a similar product


By: on 29 January 2018
I have finally found a Splitter that works !! I have gone through about 5 splitters trying to find one that will split a HDMI 2.0 signal at 4k HDCP 2.2 and this one does the job. VERY HAPPY !!
