4 Way HDMI AV Splitter

Distribute a HDMI Source to 4 Displays Simultaneously

SKU: AA6022


$44.95
RRP $99.00
In Stock

Buy In Bulk & Save!
Buy 4 to 10: Pay $42.70 ea
Buy 11 to 20: Pay $40.56 ea
Buy 21 to 100: Pay $38.54 ea




Calculate Shipping

4 Way HDMI AV Splitter

Distribute a HDMI Source to 4 Displays Simultaneously

This 4 Way HDMI AV splitter distributes 1 HDMI source to 4 HDMI output / displays simultaneously. It offers HD video solution for super market, shopping Mall, HDTV/STB/DVD/Projector /DVR factory, data control center, information distribution, conference room presentation, education and training, corporation showroom, luxurious house, etc...

FEATURES

  • One HDMI input signal split to four HDMI sink devices
  • Support  Full HD, Full 3D
  • Support 4Kx2K resolution
  • Support CEC
  • Support deep color 30bit, 36bit, 48bit
  • Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC
  • Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3 /DSD/HD(HBR)
  • Support signal retiming
  • Support input up to 15metres AWG26 HDMI standard cable length, output up to 25metres AWG26 cable length
  • No loss of quality
  • Installs in minutes

SPECIFICATIONS:

HDMI resolution ……………………………....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i

Support video color format ……………………...……..….……..24bit/deep color 30bit,36bit, 48bit

Support audio format……..….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR)

Max bandwidth……………………………………………………….………………………….340MHz

Max baud rate…………………….………………….………………………………………..10.2Gbps

Input/Output TMDS signal ………….…………………………..………... …..0.5~1.5Volts p-p(TTL)

Input/Output DDC signal ……………………………………………..……...……… 5Volts p-p (TTL)

Input cable distance..…... ……………………….…………………...………….≤15m HDMI AWG26

Output cable distance…………………………….……….…...≤25m AWG26 HDMI standard cable

Max working current………………………………..……………………………………….....1200mA

Power adapter format..Input: ……………….....AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A

Operating Temperature range……..…………….……………………………….…… (-15 to +55℃)

Operating Humidity range………………………….….…………..5 to 90%RH (No Condensation)

Dimension (L x W x H)       ……………………………….…………………………..180X68X20(mm)

Weight…..………………………………………………………..…….…………………..………320g



3 Month Warranty

SKU AA6022
Barcode # 9351634000241
Brand Playvision
Shipping Weight 0.5200kg
Shipping Width 0.150m
Shipping Height 0.070m
Shipping Length 0.220m
Shipping Cubic 0.002310m3
Unit Of Measure ea
Assembled Length 0.120m
Assembled Height 0.010m
Assembled Width 0.100m

Great solid piece of hardware

By: on 7 October 2018
I picked this splitter up here after I discovered that a lot of splitters on other websites were fairly pricey. I was also quite pleased to receive excellent customer service when I purchased the wrong model. The splitter itself is relatively small and concealable and has a strong chassis- but retains a light weight. The splitter is perfect for anyone looking to distribute to multiple displays. Unfortunately one of the ports seemed to be faulty and I occasionally get parallel green lines across my screen. Other than that small hindrance this device is definitely worth the price. 4/5 would recommend.
(4)

HDMI Splitter

By: on 15 July 2017
Excellent, efficient service!
(5)
