Palm Size True RMS Multimeter with Non-contact detector

Compact Palm Sized Multimeter

SKU: TT4556

RRP $59.95
In Stock

Buy In Bulk & Save!
Buy 4 to 10: Pay $26.95 ea
Buy 11 to 20: Pay $24.26 ea
Buy 21 to 100: Pay $21.83 ea
Buy 101 to 500: Pay $19.65 ea

Calculate Shipping

Palm Size True RMS Multimeter with Non-contact detector

Compact Palm Sized Multimeter

Palm sized digital multimeter and detector can be use to measure AC and DC voltage (Up to 300V max.), resistance (Up to 20MΩ), diode test, continuity check. True RMS measurement. Plus temperature (requires ‘K’ type Probe). 2000 counts LCD. NCD; non-contact AC detection Numerical display AC signal strength. SPT: single probe test to safely identify live/hot (>25V), neutral and ground. Compact for the tool box. Includes 2x test leads and 2x AAA batteries. You can also get the optional temperature probe (TP207). Size: 100x80x33mm.

  • True RMS up to 500Vac/dc
  • Super Compact Sized 100x80x33mm
  • Cordless AC voltage detector (metered)
  • Single Probe Test identify Live/Hot, ground, etc.
  • AC and DC Voltage measurement
  • AC and DC Current µA to 10A max
  • Auto or Manual range selection
  • Ohm (0-20MΩ) and Diode test
  • Relative measurement and hold
  • 2000 count 3.5 digit LCD display
  • Power switch with Auto-Off

  • True RMS
    2000 counts (3-1/2 digit)
    Auto / Manual ‘V’ (AC / DC) (500V)
    μA/mA/10A (AC / DC) current
    Auto / manual resistor measurement : 0 20MΩ (approx.)
    Continuity check : <50Ω Beep
    Diode check : < 2.0 V
    ‘NCD’ Non-Contact AC Voltage Detector (audible and numerical display) > 25V (AC)
    ‘SPT’ Single Probe Test AC Voltage (Audible and numerical display) > 25V : Identify‘Live/Hot’and ‘Neutral’/Ghost wire/Voltage difference/Ground/Earthing connection
    Input impedance 10MΩ (DC)
    Software calibrated
    -‘ OL ’ over range display
    Auto power off : (5 mins) or always 'ON'
    Freeze / Hold reading
    Relative reading
    Anti Burn Protection (ABP) on full range and up to 250V (AC / DC) (NOT at CURRENT range)
    Resettable fuse, 200mA
    Lοw battery indication (2.6V approx.)
    Battery powered : 2xAAA (R03/LR03)
    Dimension (LxWxD) : 100x80x33mm


3 Month Warranty

SKU TT4556
Barcode #
Brand Aus Electronics Direct
Shipping Weight 0.3000kg
Shipping Width 0.300m
Shipping Height 0.050m
Shipping Length 0.250m
Shipping Cubic 0.003750000m3
Unit Of Measure ea
Assembled Length 0.700m
Assembled Height 0.240m
Assembled Width 0.126m
