Cat III True RMS Autoranging 4000 Count DMM with Temperature
True RMS Auto Range Digital Multimeter w/ Temperature
SKU: TT4578
Cat III True RMS Autoranging 4000 Count DMM with Temperature
True RMS Auto Range Digital Multimeter w/ Temperature
A powerful true RMS multimeter that includes non-contact voltage testing, backlit LCD, and a carrying pouch. The rear of the unit has a foldout stand so you can sit the meter at a comfortable viewing angle on your desk, workbench or car.
Features:
• Backlit LCD
• Woven nylon carry pouch with room for meter and leads
• Leads and k-type thermocouple included
• Automatic (-) negative polarity indication
• Meter automatically shuts down after 30 minutes of inactivity
• Powered by 1 x 9V battery (included)
• Data hold
• Display: 4000 count
• Security Class: Cat III 600V
• Basic DVC accuracy: 0.5%
• Temperature: -20°C-760°C / -4°F-1400°F (±3%)
• Ave/RMS: True RMS
• Input impedance: - 7.8M
• Special features: Continuity, diode check, blue backlit LCD, non-contact voltage, foldout stand
Specifications
| Capacitance Ranges : 40nF, 400nF, 4µF, 40µF, 100µF |
| Capacitance Accuracy : 3% |
| Continuity indicator : Needle |
| AC Current Ranges : 400µA, 4000A, 40mA, 400mA, 10A |
| AC Current Accuracy : 1.8% |
| DC Current Ranges : 400µA, 4000µA, 40mA, 400mA, 10A |
| DC Current Accuracy : 1.5% |
| Frequency Ranges : 5Hz, 50Hz, 500Hz, 5kHz, 50kHz, 500kHz, 5Hz |
| Frequency Accuracy : 1.2% |
| Resistance Ranges : 400Ω, 4kΩ, 40kΩ, 400kΩ, 4MΩ, 40MΩ |
| Resistance Accuracy : 1.2% |
| Measures in Celcius : true |
| Outdoor / Exterior Scale : -20°C, 760°C |
| Celcius Accuracy : 3% |
| Measures in Fahrenheit : true |
| AC Voltage Ranges : 400mV, 4V, 40V, 400V, 600V |
| AC Voltage Accuracy : 2% |
| DC Voltage Ranges : 400mV, 4V, 40V, 400V, 600V |
| DC Voltage Accuracy : 1.5% |
| Data Hold : true |
| Relative Measure : true |
| Display Type : LCD |
| Display Backlight : true |
| Safety Rating Cat : Cat III |
| Safety Rating Max Volt : 600V |
| Count Maximum Reading : 4000 count |
| True RMS : true |
| Autorange : true |
| Measures duty cycle : true |
| Length : 138mm |
| Width : 68mm |
| Depth : 37mm |
| Size / Shape : 9V |
| Battery quantity : 1pc |
| Batteries included : true |
| Batteries can be replaced by user : true |
| Compartment location : Internal / In-built |
| How is battery compartment kept closed : Clip and Screw |
| Packaged Volume : 3.24l |
| Packaged Weight : 0.45kg |
| Packaged Length : 22.5cm |
| Packaged Width : 16cm |
| Packaged Height : 9cm |
| Probe rating voltage : 600V |
| Probe safety rating : Cat III |
| Meter Input Impedence : 7.8MΩ |
| Input Protection Fuse : 400mA |
| Measures diode : true |
| Foldout Stand : true |
| Casing : Plastic |
3 Month Warranty
| SKU | TT4578 |
| Barcode # | |
| Brand | Aus Electronics Direct |
| Shipping Weight | 0.3000kg |
| Shipping Width | 0.300m |
| Shipping Height | 0.050m |
| Shipping Length | 0.250m |
| Shipping Cubic | 0.003750000m3 |
| Unit Of Measure | ea |
| Assembled Length | 0.700m |
| Assembled Height | 0.240m |
| Assembled Width | 0.126m |
