SEAKING Pro-70A G2 ESC

Designed for RC Boat Racing Excellence

The Seaking 60A V4 is a compact, high-performance ESC purpose-built for Mini ECO, Mini Mono, and Mini Hydro class RC boats. With an advanced racing control core and a lightweight form factor, it meets the size, weight, and speed demands of modern boat racing.

Delivering precise throttle response, extensive tuning flexibility, and durable water-resistance, it’s your edge on the race course.

---

Key Features & Benefits

Precision Racing Control

• Professional race-tuned control core ensures responsive throttle handling

• Supports turbo timing adjustment for maximum power on demand

• Adjustable deceleration speed gives better control into corners and tight turns

Professional Water-Resistant Technology

• PCB and components coated with nano waterproofing

• Rated IP67 for complete water and dust protection—no extra sealing required

Detachable Water-Cooling Heatsink

• Efficient water-cooled design maintains lower operating temps

• Removable heatsink for size-sensitive builds or low-power setups

Cooler, Longer, Smarter Performance

• Stays cooler than competitors at 60A/16.8V full throttle

• Runs 4.5x longer before thermal protection triggers compared to similarly-sized ESCs

Built-In High-Power BEC

• Delivers up to 10A (5A continuous) current

• Selectable output voltages: 6V / 7.4V / 8.4V

• Easily powers high-torque and high-voltage servos for fast, accurate steering

Smart App Integration & Telemetry (with optional OTA Module)

• Real-time monitoring of:

  • Throttle %

  • ESC/Motor Temp

  • Voltage & Current

  • RPM

• View historical data in graph format to optimize performance

• Fully configurable via HW Link app (iOS & Android)

Turbo Function for Boats

• Unleash instant acceleration for overtakes or sprints

• Adjustable deceleration rate allows you to brake and corner with precision

Capacitor Overheating Protection

• Built-in protection prevents damage from overload and extends ESC life

Freewheeling Technology (Active Braking)

• Helps reduce ESC temperatures

• Increases deceleration speed when throttle is released

• Improves steering response during high-speed cornering

11 Fully Programmable Parameters

• Fine-tune the ESC to suit different hulls, water conditions, or racing styles

• Includes:

  • Turbo timing

  • Brake strength

  • Voltage cutoff

  • Motor direction

  • Acceleration modes and more

Upgradeable Firmware Support

• Keep your ESC up-to-date with firmware updates via:

  • Hobbywing USB LINK software (PC)

  • HW Link Mobile App (OTA module required)

---

Technical Specifications

Category	Details
Type	Brushless Marine ESC
Continuous Current	60A
Peak Current	TBD
Input Voltage	2–4S LiPo
BEC Output	6V / 7.4V / 8.4V @ 5A (10A peak)
Waterproof Rating	IP67 (nano-coated board)
Cooling	Water-cooled heatsink (detachable)
Telemetry Support	Yes (via OTA Bluetooth module – sold separately)
Programmable Items	11
ESC Programming	LCD Program Box / HW Link App
Firmware Updates	Supported (via USB or OTA)
Dimensions & Weight	Compact, lightweight — ideal for mini class

---

Perfect For:

• Mini ECO / Mono / Hydro boats

• Compact hulls with strict space constraints

• RC racers who need data-driven tuning

• Hobbyists seeking durability and race-ready tech
