Radar Microwave Ceiling Motion Detector Switch

Radar Ceiling Motion Activated Switch

An intelligent sensor switch, designed for ceiling mounting. It features configurable ambient light sensing, passive infrared motion detection and on-time delay, so you may tailor light usage and energy consumption to your exact specifications.

Daylight Harvesting is an environmentally friendly solution using Intelligent energy saving switches with a variety of different sensors to control light activation. This combination of sensors enables your lights to illuminate when you need them to, saving you on power costs and extending the life of your investment. Each switch features adjustable daylight sensing, movement sensing and on-timer delay so you may tailor light use to your installation requirements.

Radar is an active microwave motion sensor technology that is 5.8GHz 0.2mW (<0.02% the energy of a mobile phone) and offers the advantage of extended range (up to 15M) with improved detection reliability with less susceptibility to environmental influence when compared to the common PIR (Passive Infra-Red sensor) with a range of around 10 metres.


• Automatically activate and deactivate lighting for energy efficiency
• Adjustable sensors: Daylight (3~2000lx) / On-timer (10s~30min)
• 360° circle / Ø20m microwave detection
• IP65 rated weather resistant for outdoor use

Add three step energy saving to any light with sensor switches:
1) Daylight sensor: Activates motion sensor when lux levels fall below limit
2) Motion sensor: Detects movement, turns light on only when necessary
3) On-timer: Light-on duration is set only as long as is required

Dimensions    100x100x50mm
IP Rating    IP65
Rated Load    2000W Resistive/ 1000W Inductive
