HDMI 4 Port Extender Over Cat 5E/6 with 4 Receivers

Extends a HDMI Signal to 4 Displays up to 60m in range

SKU: AA6047


$299.00
RRP $599.00
Sold Out

Buy In Bulk & Save!
Buy 4 to 10: Pay $284.05 ea
Buy 11 to 20: Pay $269.85 ea
Buy 21 to 100: Pay $256.35 ea




Calculate Shipping

HDMI 4 Port Extender Over Cat 5E/6  with 4 Receivers

Extends a HDMI Signal to 4 Displays up to 60m in range

Extends a 1080p High Definition HDMI signal over Cat 5/6/7 to 4 HDMI receivers up to 60m in distance without signal loss. A cost effective solution for multi-display applications for your home, office, pubs and hotels.

Great solution for sending a set top box HDMI signal such as a Foxtel iQ2 or iQ3 to other TV's in the house or man cave.

NOTE:

Not suitable for 4K UHD HDMI 2.0 sources such as Foxtel iQ4, etc. For 4K UHD HDMI 2.0 Extenders, please click HERE.

Features:

  • One HDMI input distributes and extend to found Display by four cat6/7 cable. The extend distance can be up to 60m.
  • Support 3D
  • Support video output: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
  • Audio format support: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
  • LED Status Light:the related led light will go bright.
  • The extend distance can be up to 60m.
  • Support signal retiming
  • No loss of quality
  • Installs in minutes

Specifications:

Length of CAT-6 cable between Rx and TX - up to 60m

HDMI Input - 24/50/60fs@ 1080p / 1080i / 720p / 576p / 576i / 480p / 480i

Support audio format input - DTS-HD / Dolby-trueHD / LPCM7.1 / DTS / Dolby-AC3 / DSD

HDMI Output - 24/50/60fs@ 1080p / 1080i / 720p / 576p / 576i / 480p / 480i

Support audio format output - LPCM7.1 / DTS / Dolby-AC3 / DSD

Max bandwidth - 225MHz

Max baud rate - 6.75Gbps

Input Video signal - 0.5~1.5Volts p-p

Output DDC signal - 5Volts p-p (TT1L)

Input HDMI cable distance - ≤15m AWG26 HDMI standard cable

Output HDMI cable distance - ≤20m AWG26 HDMI standard cable

Max working current(TX) - 2000mA

Max working current(RX) - 600mA

Power adapter format(TX) - DC5V/3A

Power adapter format(RX) - DC5V/1A

Operating Temperature range - (0 to +40℃)

Operating Humidity range - 5 to 90%RH (No Condensation)

Dimension (TX) - 205x74x26(mm)

Dimension (RX) - (82X44X22) (mm) X4pcs

Weight - 750g

12 Month Warranty

SKU AA6047
Barcode # 9351634010271
Brand Playvision
Shipping Weight 1.5600kg
Shipping Width 0.300m
Shipping Height 0.100m
Shipping Length 0.330m
Shipping Cubic 0.009900000m3
Unit Of Measure ea
Assembled Length 0.250m
Assembled Height 0.010m
Assembled Width 0.200m
