EDID Ghost Emulator HDMI

HDMI EDID Emulator

Extended Display Identification Data (EDID) problems are a common cause of HDMI devices refusing to operate with each other. This handy product helps to eliminate EDID related signal issues by emulating or replacing the EDID configuration of a device. Many HDMI equipped products use specialised EDID configurations which can cause signal problems when distributing through splitters and extenders. This is quite common on Windows 7 & Samsung devices. This feeder allows you to read, modify and rewrite the EDID portion of the HDMI signal. HDCP encryption is passed through. Includes a USB lead for powering from your TV/source alternatively you are able to use a USB mains adaptor (sold separately). Max emulation pass through 4K @ 30Hz.


Features

• 4K UHD HDMI EDID Feeder with Splitter Function (HDCP Engine built in)
• Allow to restore 4 customized EDID information
• Avoid computer from deactivating or inactive HDMI ports
• Copy EDID from the connecting display Economical, durable and dependable EDID Ghost (DDC Ghost)
• Support over 100 popular resolution
• Emulator maximum supports up to 4K UHD@30Hz 3840 x 2160 Resolution
• Built in EDID/HDCP Engine
• Built in Splitter Function
• Incorporate EDID and HDCP handling procedures for continuous video output
• Auto configuring EDID from the connecting display
• Easy and Ready to Go

Specifications

• Input: HDMI x 1
• Output: HDMI x 2 (Main x1, Aux x1)
• HDCP Engine: Yes
• Resolution (Max.): 3840 x 2160@30Hz
• Status LED: x 2 Dual Color (Blue & Green)
• Power Supply: 5V DC (mini-USB)
• Housing: Metal
• Dimensions: 24 x 98 x 64 mm
• Weight: 200g

  *Specifications are subject to change without notice.
