XeRun 4268SD 2200KV G3 Off-Road Brushless Motor

The Hobbywing XeRun 4268SD G3 2200KV motor is engineered for 1/8th scale off-road RC buggies and truggies, delivering explosive power and smooth sensored control. Designed to pair seamlessly with the Hobbywing XeRun XR8 ESC series, it provides precise throttle response, enhanced efficiency, and reliable performance under the toughest racing conditions.

Key Features

• Pure Sensored Mode – Built-in chip allows full-sensored operation when paired with XR8 ESCs, ensuring smoother control and improved drivability.

• Turbo Timing Technology – When used with compatible XR8 ESCs, Turbo Timing unleashes up to 50% more top speed, giving you the edge on the track.

• Adjustable Mechanical Timing – Fine-tune power delivery with 20°–40° timing adjustment (CW/CCW) to match your racing setup.

• Efficient & Cooler Running – Optimized G3 design reduces internal resistance by up to 6%, resulting in lower temperatures and improved efficiency over the previous G2 motors.

• Durable & Reliable – Features Hobbywing’s patented “error-free” Hall sensor system, CNC-machined aluminum ribbed can, IP5X dustproof rating, and high-quality bearings for long-lasting performance.

• Lightweight Design – At only 285g, the 2200KV model is up to 45g lighter than comparable motors, improving handling and chassis balance.

• Low Cogging Torque – Ensures smooth low-speed control, making it ideal for competitive off-road racing.

Technical Specifications

• Scale: 1/8th Off-Road

• Brushless / Sensored: Yes

• Pole Count: 4

• KV Rating: 2200KV

• LiPo Compatibility: 2S–6S

• No-load Current: 4.5A

• Outer Diameter: 42mm

• Length: 67.8mm

• Shaft Diameter: 5.0mm

• Weight: 285g

• Front Bearing: D16×D5×T5

• Rear Bearing: D11×D5×T5

• Adjustable Timing: 20°–40°

• Protection: IP5X dustproof rating

Why Choose the 2200KV Model?

The 4268SD 2200KV G3 is the perfect choice for racers needing higher RPMs and more aggressive power delivery than the 1900KV version. It excels on medium-to-large off-road tracks where extra speed is crucial, without sacrificing thermal stability or long-term durability.
