Platinum 120A V5 ESC

Platinum 120A V5 ESC

Brushless Electronic Speed Controller

SKU: TR9676

$299.95
RRP $599.95
In Stock
Buy In Bulk & Save!
Buy 4 to 10: Pay $284.95 ea
Buy 11 to 20: Pay $270.70 ea
Buy 21 to 100: Pay $257.17 ea


Calculate Shipping

Description

Platinum 120A V5 ESC

Brushless Electronic Speed Controller

Product Name

Platinum 120A V5
Product Number
  30203402
Type
Brushed/Brushless BL
High Voltage/Regular Regular
Specifications
Cont./Peak Current 120A/150A
Input Voltage 3-8S Lipo
BEC Output
Switch Mode:5-12V & Cont. 10A，Peak 30A
Wires & Connectors
Input Wires
Red-10AWG-150mm*1/Black-10AWG-150mm*1
Output Wires Black-12AWG-100mm*3
Input Connectors No
Output Connecotors 4.0mm Gold Connectors (Female)
ESC Programing via
Transmitter Not Support
LED Program Card Not Support
LED Program Box Not Support
LCD Program Box Supported
OTA Programmer Supported
Program Port Separate Program Port
Firmware
Firmware Upgrade Supported
Telemetry Function
  Mikado VBarï¼›Futaba S.Bus2ï¼›etc.
Size & Weight
Size
83.2*37.1*22.5mm(without fan)
Weight 150.4g (with wires, no fan)
Application scope

420-520 class electric helicopter (main blade length 420-520mm),or fixed-wing

Care/Warranty

3 Month Warranty

Specifications

SKU TR9676
Barcode # 9351634086733
Brand Aus Electronics Direct
Shipping Weight 0.1510kg
Shipping Width 0.200m
Shipping Height 0.030m
Shipping Length 0.200m
Shipping Cubic 0.001200000m3
Unit Of Measure ea
