36RPM 12VDC Reversible Gearhead Motor

Compact reversible DC motor with gearbox head

Mid-range reversible DC motor with gearbox head for simple drivetrain applications. Ideal for driving wheels or other traction devices.

Operating Voltage: 12VDC

At Stall:
Torque:  14kg.cm
Current: 1.7A

Specifications

DC Voltage : 4.5V, 18V
Item connection : Solder Tags
Packaged Volume : 0.21l
Packaged Weight : 0.09kg
Packaged Length : 6cm
Packaged Width : 11cm
Packaged Height : 3.2cm
Type : Planetary/Orbital
Gear Ratio : 244:1
Adjustable Gear : false
Pre-assembled Gear : true
Motor Type : Gearhead
Motor Nominal Voltage : 12V
No load current : 70mA
No load RPM : 36RPM
Full load current : 1.38A
Full load torque : 12kg.cm
Max efficiency : 65.9%
Max efficiency power : 3.8W
Max efficiency RPM : 29RPM
Maximum efficiency torque : 2.2kg.cm
Max. efficiency current : 0.32A
Shaft diameter : 5mm
Shaft length : 9mm
SKU TM1024
Barcode # 9351634072743
Shipping Weight 0.1000kg
Shipping Width 0.050m
Shipping Height 0.050m
Shipping Length 0.050m
Shipping Cubic 0.000125000m3
