12V 2.5A DC Uninterruptible Power Supply

12V 2.5A DC UPS for Modems, Switch or Router

A compact DC UPS designed to connect inline with your ordinary 12VDC mains power adaptor. In the case of a power outage, the internal battery will keep your equipment operating for longer. Three interchangeable DC connectors are supplied to suit a range of devices such as a modem, network switch, router, video device, surveillance systems or lights. An integrated smart charger ensures the internal 18650 Li-ion batteries are charged, and adjusts the charge current based on the current draw to the device you are powering. The rated output is 2.5A at 12V but 3A can be provided for a short time. Four status LEDs indicate the UPS charge status, and safety features include over-charge, over-discharge, over-current, and short-circuit.

Features:

- 2.5A Output

- DC Power

- Built-in rechargeable Li-ion battery

- Integrated smart charger

- LED status indicators


DC Connectors (mm):

Input: 5.5OD x 2.1ID - Center Tip Positive

Output: 5.5OD x 2.5ID - Center Tip Positive


Adaptors (mm):

5.5OD/2.5ID Male to 5.5OD/2.1ID Female - Center Tip Positive

3.5OD/1.35ID Male to 5.5OD/2.5ID Female - Center Tip Positive

5.5OD/2.1ID Male to 3.5OD/1.35ID Female - Center Tip Positive

Specifications

DC current rating : 2.5A

DC Current Surge Rating : 3A

DC Voltage : 12.2V

Length : 138mm

Width : 60mm

Height : 24mm

Weight : 260g

DG UN Number : 3481

DG Ship Name : 3481 - Lithium Ion Batteries Packed In Equipment

DG Class : 9

DG Pack Group : II - Medium Danger

DG Hazardous Chemical Code : 4W

Battery Watt Hour Rating (Required for Lithium Batteries) : 7.4Wh

Packaged Volume : 1.01l

Packaged Weight : 0.33kg

Packaged Length : 19.7cm

Packaged Width : 15.5cm

Packaged Height : 3.3cm

Recharging Voltage : 11.8V, 12.5V

Standard Recharge Current : 0.8A

Battery Chemical Composition : Lithium Ion

Type of battery : 18650
