5 Port HDMI 2.0 18GBPS Switcher

5 Port HDMI 2.0 Switcher - Supports HDR and HDCP 2.2

SKU: AA6016

RRP $139.00
Sold Out

Buy In Bulk & Save!
Buy 4 to 10: Pay $56.95 ea
Buy 11 to 20: Pay $54.10 ea
Buy 21 to 100: Pay $51.40 ea

Calculate Shipping

5 Port HDMI 2.0 18GBPS Switcher

5 Port HDMI 2.0 Switcher - Supports HDR and HDCP 2.2

This is a high performance 5 HDMI AV input Selector to 1 HDMI output switcher box. 4K HDMI Switch supports all 3D TV formats in addition to all HDTV formats up to 4Kx2K. Furthermore, the remote control gives complete control over the selection of sources and makes the device incredibly user friendly.

Works with Foxtel IQ4.


  • Compliant with HDMI2.0, HDCP2.2 and DVI 1.0;

  • Support video format up to 4k @ 60Hz with 24bit RGB/YcbCR 4:4:4/YCBCR 4:2:2,and up to 4k2k@60Hz with 12bit YCBCR 4:2:0.

  • Support 3D frame sequential video format up to 1080p@60.

  • Support high resolution VESA mode video format up to QSXGA@60Hz.

  • Supports Dolby Atmos, LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio.

  • Supports smart auto switch function.

  • Supports IR and Panel button control.


  • UHD 5x 1 HDMI Switcher (1Pcs)

  • 5V/1A DC power adaptor (1Pcs)

  • Remote Control (1Pcs)

  • 38KHz IR Receiver Cable (1Pcs)

  • User manual (1pcs)


  • Video Bandwidth: 18Gbps

  • Input Ports: 5x HDMI (Female type)

  • Output Ports: 1 x HDMI (Female type)

  • Output Resolution: 480i ~1080p50/60, 4k2k@60Hz with 12bit YCBCR 4:2:0,VGA~UXGA

  • ESD Protection: Human Body model: ±8 kV (air-gap discharge) ±4 kV (contact discharge)

  • Power Supply: 5 V/1A DC

  • Dimensions: 64 mm (W)×155mm(D)×17 mm (H)

  • Weight: 180 g

  • Chassis Material: Metal

  • Silkscreen Color: Black

  • Operating Temperature: 0 °C~40 °C/ 32 °F~104 °F

  • Storage Temperature: −20 °C ~ 60 °C/−4 °F ~140 °F

  • Relative Humidity: 20~90 % RH (non-condensing)


Do I need a HDMI Switcher of a HDMI Splitter?




12 Month Warranty

SKU AA6016
Barcode # 9351634000210
Brand Playvision
Shipping Weight 0.4900kg
Shipping Width 0.150m
Shipping Height 0.070m
Shipping Length 0.210m
Shipping Cubic 0.002205000m3
Unit Of Measure ea
Assembled Length 0.200m
Assembled Height 0.010m
Assembled Width 0.200m

Good Value Switch

By: on 13 January 2021
Picked this up to connect a bunch of video game consoles to my TV. Works great with a PS4 Pro. It supports 4K@60hz with HDR on. Tried connecting an OSSC to it. Works on every mode except 5x with my SNES. On 5x it displays a picture but blanks out often. Overall though I am very happy with the purchase.

Works exactly as described

By: on 3 December 2018
I bought this primarily for the auto-switch functionality, which works superbly and automatically switches to an input as soon as it detects a change from no signal to signal. Highly recommend.

5 Port HDMI to One

By: on 10 September 2018
Seems to work exactly as described - I bought it as I had a previous 3 to 1 HDMI powered switch (different brand) but for some reason every 20 to 30 minutes it would cycle off and on again interrupting the source. This new 5 to 1 HDMI has had no issues like that - exact same set up, just reconnected all relevant cables and finally able to watch a show / movie without annoying power out issues. Easy to set up and use and delivers high quality image throughput. Excellent quick delivery to Melbourne also.

HDMI 5 Port Switch

By: on 9 March 2018
Good product good service. Would like to have purchased with the recent price drop. I would be very happy to receive the value difference ;) Very helpful addressing an inquiry on CEC.
