8 WAY HDMI V2.0 SPLITTER with HDR

Supports HDCP Convertion

SKU: AA6092


$149.00
RRP $249.00
Pre-order expected dispatch date 31 May 2019 (subject to change)

Buy In Bulk & Save!
Buy 4 to 10: Pay $141.55 ea
Buy 11 to 20: Pay $134.47 ea
Buy 21 to 100: Pay $127.95 ea




Calculate Shipping

8 Way HDMI 2.0 AV Splitter - Connect a HDMI output to 8 Displays

This 1 by 8 HDMI UHD Splitter with HDCP 2.2 is an advanced solution for splitting a single HDMI input to eight HDMI outputs. It provides high performance audio and video output through HDMI cables up to 4K2K@60Hz (YUV420) resolution and is capable of receiving and transmitting up to 18Gbps of bandwidth with no data loss.

Perfect for new 4K video sources such as IQ4, Playstation 4 Pro or Xbox S One and other devices that require 4K2K@60Hz with 24bit RGB/YCBCR 4:4:4 / YCBCR 4:2:2 specifications.

Also has a built in HDCP Converter / Stripper. It is able to convert HDCP 2.2 to HDCP 1.4 or HDCP 1.4 to HDCP 2.2.

Supporting the latest features you can be assured of reliable and high quality HDMI distribution.

Package:

  • UHD 1x8 HDMI Splitter (1Pcs)
  • 5V/1A DC power adaptor (1Pcs)
  • User manual (1pcs)

Feature:

  • One HDMI 2.0 input signal split to eight HDMI 2.0 sink devices
  • Support  HDR
  • Support 4K*2K @60Hz resolution
  • Support HDCP 1.4 to HDCP 2.2 conversion
  • Support HDCP 2.2 to HDCP 1.4 conversion
  • Support deep color 24bit, 30bit, 36bit
  • Video Format Support: 4Kx2K/60Hz 10Bit YcbCr4:2:0; 4Kx2K/60Hz 12Bit  YcbCr 4:2:0 ; 4Kx2K/60Hz 8Bit YcbCr 4:4:4/ YcbCR4:2:0 (Note: only supports standard HDMI Source YcbCR4:4:4 Signal)
  • Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC
  • Digital audio format, Dolby Atmos, DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
  • HDMI Input Cable length can be up to 10m and HDMI Output Cable length up to 10 when transmitting 1080P signal by using standard AWG24 HDMI Cable;
  • HDMI Input Cable length can be up to 5m and HDMI Output Cable  length up to 5m when transmit the 4Kx2Knal by using standard AWG24 HDMI Cable;
  • Support signal retiming
  • No loss of quality
  • Installs in minutes

Specifications:

HDMI resolution ………………4K@60Hz /4K@30Hz/1080P/1080i/720p/576p/576i/480P/480i

Support video color format ……………………………..……………. 24bit/deep color 30bit,36bit

Support audio format……………………DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

Max bandwidth………………………………………………………………………………..600MHz

Max baud rate……………….…….………………….……………………………………..18Gbps

Input/Output TMDS signal ………….…………………………..……......… 0.5~1.5Volts p-p(TTL)

Input/Output DDC signal ………………………………………………..………… 5Volts p-p (TTL)

Input cable distance..…... …………….…. ≤10m(1080P)/5M(4K) AWG24 HDMI standard cable

Output cable distance………………………≤10m(1080P)/5M(4K) AWG24 HDMI standard cable

Max working current……………………………………………………………………….....2000mA

Power adapter format..Input: ……………..AC (50HZ, 60HZ) :100V-240V; Output: DC12V/3A

Operating Temperature range……..…………….………………………………………-0 to +40℃

Storage Temperature range…………………………………………………………… -20 to +60℃

Operating Humidity range………………………….….……….5 to 85%RH (No Condensation)

Storage Humidity range………………………….….……….…5 to 95%RH (No Condensation)

Dimension (L x W x H) ……………………………….…………………. ….………280X136X25(mm)

Weight…..………………………………………………………..…….…..………………………882g

12 Month Warranty

SKU AA6092
Barcode # 9351634006069
Brand Aus Electronics Direct
Shipping Weight 1.3700kg
Shipping Width 0.180m
Shipping Height 0.090m
Shipping Length 0.380m
Shipping Cubic 0.006156000m3
Unit Of Measure ea

8 Way 4K Splitter

By: on 25 April 2019
I have a complex 1080P/4K HDMI setup and this splitter worked a treat where others haven't. The item arrived on time and very happy.
(5)

8 way HDMISplitter

By: on 2 February 2019
Works great simply plugged it in and I now have Foxtel on several TVs
(5)

Up and running again

By: on 20 October 2018
I recently upgraded to an iQ4 Foxtel box so that forced me to upgrade my 8 way 1080P splitter to a 4K one. I bought one from another supplier and it didn't work. Some of the (non 4K) TVs that were connected to the splitter no longer worked at all. I then found this 4K splitter from Aus Electronics Direct and it worked perfectly. Now I can watch 4K on all of the (4K) TVs that are connected to this splitter, plus the other TVs still work. Very happy.
(5)
