2 Way HDMI AV Splitter

Connects 2 LCD or TV to a single HDMI Source

SKU: AA6020


$32.95
RRP $59.95
In Stock

Buy In Bulk & Save!
Buy 4 to 10: Pay $31.30 ea
Buy 11 to 20: Pay $29.73 ea
Buy 21 to 100: Pay $28.25 ea




Calculate Shipping

2 Way HDMI AV Splitter - Distribute a HDMI Source to 2 Displays Simultaneously

This 2 Way HDMI AV Splitter distributes 1 HDMI source to 2 HDMI display outputs simultaneously. It offers HD video solution for super market; shopping mall; HDTV, STB, DVD, projector factory; data control center; information distribution; conference room presentation; education and training; corporation show room; home theater, etc.

FEATURES

  • One HDMI input signal split to two HDMI output devices
  • Support 3D full HD
  • Support 4K X 2K
  • Supports HDMI 1.4
  • Support CEC
  • Support deep color24bits  30bit, 36bit 48 bits
  • Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC
  • Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
  • Support signal retiming
  • Support input up to 10metres AWG26 HDMI standard cable length,output up to 10metres AWG26 cable length
  • No loss of quality
  • Installs in minutes

SPECIFICATIONS:

HDMI resolution ………………………....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i

Support video color format …………………………..….24bit/deep color 30bit,36bit 48bits

Support audio format………..DTS/HD/Dolby-tureHD/LPCM7.1/DTS/Dolby-AC3/DSD/HD(HBR)

Max bandwidth…………………………………………………………………..340MHz

Max baud rate……………….…….………………….………………………..10.2Gbps

Input/Output TMDS signal ………….…………………………..……...… 0.5~1.5Volts p-p(TTL)

Input/Output DDC signal ……………………………………………..………… 5Volts p-p (TTL)

Input cable distance..…... …………….………………….≤10m AWG26 HDMI standard cable

Output cable distance……………………………….…...≤10m AWG26 HDMI standard cable

Max working current……………………………………………………………………….....150mA

Power adapter format..Input: ……………....AC (50HZ, 60HZ) :100V-240V; Output: DC5V/1A

Operating Temperature range……..…………….………………………………… (-15 to +55℃)

Operating Humidity range………………………….….……….5 to 90%RH (No Condensation)

Dimension (L x W x H)       ……………………………….……………….…61.3x65.3x20.7 (mm)

Weight…..………………………………………………………..…….…..……………………105g



3 Month Warranty

SKU AA6020
Barcode # 9351634000234
Brand Playvision
Shipping Weight 0.2700kg
Shipping Width 0.130m
Shipping Height 0.080m
Shipping Length 0.140m
Shipping Cubic 0.001456m3
Unit Of Measure ea
Assembled Length 0.120m
Assembled Height 0.010m
Assembled Width 0.100m

2 Way HDMI AV Splitter

By: on 10 August 2018
Absolutely rate your service highly and would recommend you to friends.
(5)

Port spacing

By: on 21 August 2017
The following is not a criticism of the product but is information in regard to the law of unintended consequences. This product worked as expected when it was plugged in, however I encountered a problem with regard to the port spacing when I used a converter from DVI to HDMI in the input port. The width of the converter blocked access to one of the output ports thus rendering the switch a single output device.
(4)

Worked great for IQ3

By: on 17 August 2017
This version of the HDMI splitter worked perfectly for splitting the HDMI signal from my Foxtel IQ3 box. We got full HD to an outdoor TV via a 30m Powered HDMI cable. Highly recommend.
(5)

HDMI splitter

By: on 9 June 2016
Needed to be able to send the video and sound to either a projector or a lcd tv, this device is simple and effective. Couldn't have been easier.
(5)
