80mm 240V AC Ball Bearing Cooling Fan

Cooling Fans and Accessories

A 240V AC 80mm Sunon Ball Bearing Cooling Fan with diecast aluminium frame.

Designed for long-life and minimal noise operation.

Sunon® fans are manufactured to a very high standard and hold CSA and UL listings.



SPECIFICATIONS:

Mechanical Characteristics

• Motor Design: Shaded pole motor construction
• Motor Protection: Impedance protected
• Bearing System: Precision ball bearing system
• Frame Material: Die-cast aluminium
• Blade Material: Thermoplastic PBT of UL94V-0
• Direction of Rotation: Counter clockwise viewed from the front of the fan blade
• Mounting Holes: 8x 4.3mm holes
• Weight: 260g
• Dimensions: 80 x 80 x 25mm

Electrical Characteristics

• Rated Voltage: 220-240V AC at 50/60Hz
• Rated Current: 0.07/0.07A
• Rated Power: 14/13.5W
• Operating Voltage Range: 185-245V AC
• Starting Voltage: 185V AC
• Operating Temperature: -10°C ~ +70°C
• Storage Temperature: -40°C ~ +70°C

Performance Characteristics

• Rated Speed: 2450/2900 RPM ±10%
• Air Flow: 18/22 CFM
• Static Pressure: 0.13/0.19 Inch-H2O
• Noise Level: 30/34.5dB(A)
• Insulation Resistance: 500MΩ at 500V DC
• Dielectric Strength: 1500V AC for one second
